ABB DSDI110AV1 3BSE018295R1: Digital Input Module for Industrial Automation
Product Overview
The ABB DSDI110AV1 3BSE018295R1 is a high – performance digital input module designed to play a crucial role in industrial automation systems. As part of ABB’s comprehensive range of industrial control products, this module is engineered to interface with various field devices and collect digital signals for further processing within the automation system.
This digital input module is typically used in Programmable Logic Controllers (PLCs) and Distributed Control Systems (DCS). It can be easily integrated into ABB’s AC500 and other compatible control systems, enhancing the system’s ability to monitor and respond to digital events. With its reliable signal acquisition capabilities, Whatsapp:+86 18859254943.the DSDI110AV1 3BSE018295R1 ensures that industrial processes can be accurately monitored, enabling timely decision – making and control actions.
In industrial automation ecosystems, the DSDI110AV1 3BSE018295R1 serves as an essential link between the physical world of sensors and actuators and the digital control logic. It provides a stable and accurate way to detect the status of switches, sensors, and other digital devices, which is vital for maintaining the smooth operation of manufacturing lines, power plants, and other industrial facilities.
DSDI110AV1 3BSE018295R1
Technical specifications
| Parameter name | Parameter values |
|---|---|
| Product models | ABB DSDI110AV1 3BSE018295R1 |
| Manufacturer | ABB |
| Product type | Digital Input Module |
| Number of input channels | 16 |
| Input voltage range | 24 V DC ± 20% |
| Maximum current per channel | 10 mA |
| Response time | ≤ 10 ms |
| Isolation voltage | 500 V AC |
| Dimensions (W x H x D) | 121.5 mm x 100 mm x 125 mm |
| Weight | 0.3 kg |
| Operating temperature | -25°C to +70°C |
| Storage temperature | -40°C to +85°C |
| Humidity | 5 – 95% RH (non – condensing) |
| Certifications | CE, UL, RoHS |
Main features and advantages
High – density input channels: The DSDI110AV1 3BSE018295R1 comes with 16 input channels, allowing it to handle a large number of digital signals in a single module. This high – density design reduces the need for multiple modules, saving space in the control cabinet and simplifying wiring.
Wide input voltage tolerance: With an input voltage range of 24 V DC ± 20%, the module can tolerate fluctuations in the power supply. This feature makes it suitable for use in industrial environments where voltage stability may be an issue, ensuring reliable operation even under less – than – ideal power conditions.
Fast response time: The response time of ≤ 10 ms enables the module to quickly detect changes in the input signals. This is crucial for applications that require real – time monitoring and control, such as high – speed manufacturing processes or emergency shutdown systems.E-mail :sales@ygplc.com.
Electrical isolation: The 500 V AC isolation voltage provides protection against electrical interference and short – circuits. It helps to prevent damage to the module and other components in the control system,enhancing the overall reliability and safety of the industrial automation setup.
Rugged design: The module is designed to withstand harsh industrial environments. It can operate within a wide temperature range from – 25°C to +70°C and tolerate high humidity levels (5 – 95% RH non – condensing). This makes it suitable for use in various industries, including chemical, mining, and automotive.Whatsapp:+86 18859254943.
Application field
Manufacturing industry: In manufacturing plants, the DSDI110AV1 3BSE018295R1 is used to monitor the status of conveyor belts, robotic arms, and other production equipment. It can detect the presence or absence of products on the conveyor, the position of robotic joints, and the status of safety switches. This information is then used by the PLC to control the production process, ensuring smooth operation and high – quality output.
Power generation: In power plants, the module can be used to monitor the status of circuit breakers, relays, and other electrical devices. It helps to detect faults and abnormal conditions in the power grid, enabling operators to take timely corrective actions. For example, it can detect when a circuit breaker trips and send an alarm signal to the control room.E-mail :sales@ygplc.com.
Water treatment plants: In water treatment facilities, the DSDI110AV1 3BSE018295R1 can be used to monitor the status of pumps, valves, and sensors. It can detect the level of water in tanks, the flow rate of water, and the status of filtration systems. This information is used to control the water treatment process, ensuring the quality and quantity of treated water.
Automotive industry: In automotive manufacturing, the module can be used to monitor the status of assembly line equipment, such as welding robots and paint booths. It helps to ensure the safety and efficiency of the production process by detecting faults and malfunctions in real – time.
DSDI110AV1 3BSE018295R1
Related products
- ABB DSDI111AV1 3BSE018296R1: This is an upgraded version of the DSDI110AV1 3BSE018295R1 with enhanced input filtering capabilities. It can better handle noisy input signals, making it more suitable for applications in electrically noisy environments.Whatsapp:+86 18859254943.
- ABB DSOU110AV1 3BSE018297R1: A digital output module that can be used in conjunction with the DSDI110AV1 3BSE018295R1. It allows the control system to send digital signals to actuators, such as motors, solenoids, and valves.
- ABB AC500 PLC: A programmable logic controller that is fully compatible with the DSDI110AV1 3BSE018295R1. It provides the processing power and control logic to manage the input signals from the module and make decisions based on the programmed algorithms.
- ABB S800 I/O system: A distributed I/O system that can be integrated with the DSDI110AV1 3BSE018295R1. It offers more flexibility in terms of system configuration and expansion, allowing for the connection of multiple modules over a larger area.E-mail :sales@ygplc.com.
- ABB CI854AK03 3BSE030220R1: A communication module that can be used to connect the DSDI110AV1 3BSE018295R1 to a PROFIBUS DP network. This enables the module to communicate with other devices on the network, facilitating data exchange and system integration.
Installation and maintenance
Preparation before installation: Before installing the DSDI110AV1 3BSE018295R1, ensure that the power supply is turned off to avoid electrical shock. Mount the module on a DIN rail in the control cabinet, making sure it is securely fastened. Check the wiring diagram provided by ABB to ensure correct connection of the input channels. Use proper cable management techniques to avoid signal interference. Verify that the input voltage source is within the specified range of 24 V DC ± 20%.
Maintenance Recommendations: Regularly inspect the module for any signs of physical damage, such as cracks or loose connections. Check the input signals for proper operation by monitoring the status indicators on the module. Clean the module periodically to remove dust and debris, which can affect its performance. If any faults are detected, refer to the ABB troubleshooting guide. Replace the module if necessary, following the proper installation procedures.
DSDI110AV1 3BSE018295R1
Product guarantee
Chengdu Sunshine XiHe Electric Co., LTD, a leading enterprise in the industrial control industry founded in 2007, offers a 1 – year warranty on the ABB DSDI110AV1 3BSE018295R1. Our company, as an import and export trade distribution company, specializes in selling major brands of industrial control parts, including many cold – discontinued models. We have a large stock of products, ensuring that we can meet the urgent needs of customers looking for spare parts.Whatsapp:+86 18859254943.
We are confident in the quality of the ABB DSDI110AV1 3BSE018295R1 and are committed to providing excellent after – sales service. Our team of technical experts is available 24/7 to provide technical support and assistance. If you encounter any issues with the product during the warranty period, we will repair or replace it free of charge.E-mail :sales@ygplc.com.
