5SHX2645L0004 | 5SHX2645L0002 | 5SHX2645L0006 | High – Power Thyristor Module

Brand:ABB

Model:5SHX2645L0004

Product Parameters

• Condition: Brand – new, thoroughly inspected and tested at the factory to ensure top – notch quality and performance.
• Warranty: A standard 1 – year warranty is provided, covering defects in materials and workmanship under normal operating conditions. For specific warranty terms and conditions, please refer to the official ABB documentation.
• Package: The product is carefully packed in a sturdy wooden crate with anti – static foam and shock – absorbing materials to protect it during transportation. It also includes an installation manual and a certificate of compliance.
• Mounting Type: It supports both flat – surface mounting and rack – mounting. The module comes with pre – drilled holes for easy and secure installation.
• Dimensions: The module has dimensions of approximately 250mm (length) x 150mm (width) x 80mm (height), which is designed to fit well into standard power conversion cabinets and systems.
• Surge Protection: Equipped with advanced surge protection circuitry that can withstand high – energy transient surges up to 6 kV, safeguarding the module from voltage spikes caused by lightning strikes, switching operations, or other electrical disturbances.
• Compliance: Complies with international standards such as IEC 60747 (Semiconductor devices), UL 1557 (Safety Standard for Power Semiconductor Devices), and relevant environmental protection directives like RoHS.
• Application: Ideal for a wide range of high – power applications including industrial motor drives, high – voltage direct current (HVDC) transmission systems, power supplies for large – scale manufacturing equipment, and traction applications in the railway industry.



Product Introduction

The 5SHX2645L0004 also offers excellent electrical isolation between the thyristor chips and the module’s housing. This isolation helps to prevent electrical interference and ensures the safety of the operators and other components in the system.

Product Application Industry

1. Industrial Motor Drives
   In industrial motor drives, the 5SHX2645L0004 is used to control the speed and torque of large – scale motors. By precisely controlling the power supplied to the motors, the module enables smooth and efficient operation of industrial machinery such as pumps, compressors, and conveyor belts. This not only improves the productivity of the manufacturing process but also reduces energy consumption.
2. High – Voltage Direct Current (HVDC) Transmission Systems
   HVDC transmission systems are crucial for long – distance power transmission and grid interconnection. The 5SHX2645L0004 plays a vital role in these systems by converting alternating current (AC) to direct current (DC) and vice versa. Its high – power handling capacity and high – efficiency design make it an ideal choice for HVDC converters, which are essential for minimizing power losses during long – distance transmission.
3. Power Supplies for Large – Scale Manufacturing Equipment
   Large – scale manufacturing equipment such as arc furnaces, electrolysis plants, and welding machines require high – power and stable power supplies. The 5SHX2645L0004 can be used to build high – power rectifiers and inverters for these applications, providing the necessary electrical power with high precision and reliability.
4. Traction Applications in the Railway Industry
   In the railway industry, the 5SHX2645L0004 is used in the traction systems of electric trains and locomotives. It helps to convert the electrical power from the overhead lines or third rails into the appropriate voltage and current for the traction motors, enabling the efficient and reliable operation of the trains.
5. Renewable Energy Systems
   In renewable energy systems such as wind farms and solar power plants, the 5SHX2645L0004 can be used in power converters to connect the renewable energy sources to the grid. Its high – efficiency and high – power handling capabilities make it suitable for converting the variable – frequency and variable – voltage power generated by wind turbines and solar panels into stable AC power that can be fed into the grid.
