ABB CB801 3BSE042245R1: High-Speed PROFIBUS DP Communication Interface for Industrial Automation
Product Overview
The ABB CB801 3BSE042245R1 is a high-performance PROFIBUS DP communication interface module designed to enable seamless integration of industrial devices in automation systems. As part of ABB’s Panel 800 series, this module acts as a slave expansion module, facilitating real-time data exchange between controllers, sensors, actuators, and other PROFIBUS DP-compliant devices. With support for PROFIBUS DP V1 and V2 protocols, the CB801 3BSE042245R1 ensures reliable communication in complex industrial environments, including manufacturing plants, power generation facilities, and process control systems.
Engineered for precision and durability, the CB801 3BSE042245R1 features a compact design (121.5 mm × 49.5 mm × 153 mm) and lightweight construction (0.2 kg), allowing easy installation in confined spaces. It operates efficiently within a wide temperature range (-20°C to +70°C) and withstands electromagnetic interference, ensuring stable performance in harsh industrial settings. The module supports 9.6 kbps to 12 Mbps data transfer rates, enabling rapid response times for critical applications like robotics, conveyor systems, and quality control equipment.
In automation ecosystems, the CB801 3BSE042245R1 bridges the gap between legacy systems and modern industrial networks. Its compatibility with ABB’s Panel 800 HMI panels and AC500 PLCs simplifies system integration, while SD card programming eliminates the need for additional tools, reducing setup time by up to 50% . By optimizing data flow and minimizing latency, the module enhances operational efficiency and reduces downtime in mission-critical processes.
CB801 3BSE042245R1
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Model | ABB CB801 3BSE042245R1 |
| Manufacturer | ABB |
| Product Type | PROFIBUS DP Communication Interface Module |
| Communication Protocol | PROFIBUS DP V1/V2 |
| Data Transfer Rate | 9.6 kbps to 12 Mbps |
| Input Voltage | 24 V DC ±10% |
| Power Consumption | 1.5 W |
| Dimensions (W×H×D) | 121.5 mm × 49.5 mm × 153 mm |
| Weight | 0.2 kg |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Certifications | CE, UL, RoHS |
| Warranty | 1 year |
Key Features and Advantages
High-Speed Data Transfer:
The CB801 3BSE042245R1 supports 12 Mbps data rates, ensuring real-time synchronization of complex automation processes. This capability is critical for applications like high-speed packaging lines, where millisecond-level response times are essential.
The CB801 3BSE042245R1 supports 12 Mbps data rates, ensuring real-time synchronization of complex automation processes. This capability is critical for applications like high-speed packaging lines, where millisecond-level response times are essential.
Rugged Industrial Design:
Built to withstand extreme temperatures, humidity, and electromagnetic interference, the module maintains stability in challenging environments such as chemical plants or outdoor power stations. Its IP20-rated enclosure protects against dust and accidental contact, ensuring long-term reliability.
Built to withstand extreme temperatures, humidity, and electromagnetic interference, the module maintains stability in challenging environments such as chemical plants or outdoor power stations. Its IP20-rated enclosure protects against dust and accidental contact, ensuring long-term reliability.
Seamless Integration:
Compatible with ABB’s Panel 800 HMIs and AC500 PLCs, the CB801 3BSE042245R1 simplifies system expansion. It also integrates with third-party PROFIBUS DP devices, enabling retrofitting of legacy systems without hardware replacements.
Compatible with ABB’s Panel 800 HMIs and AC500 PLCs, the CB801 3BSE042245R1 simplifies system expansion. It also integrates with third-party PROFIBUS DP devices, enabling retrofitting of legacy systems without hardware replacements.
CB801 3BSE042245R1
User-Friendly Configuration:
The module’s SD card programming allows users to upload configurations directly, eliminating the need for specialized software. This feature reduces commissioning time and enhances flexibility for field technicians.
The module’s SD card programming allows users to upload configurations directly, eliminating the need for specialized software. This feature reduces commissioning time and enhances flexibility for field technicians.
Cost-Effective Solution:
By consolidating communication tasks into a single module, the CB801 3BSE042245R1 minimizes hardware requirements and associated costs. Its energy-efficient design (1.5 W power consumption) further reduces operational expenses.
By consolidating communication tasks into a single module, the CB801 3BSE042245R1 minimizes hardware requirements and associated costs. Its energy-efficient design (1.5 W power consumption) further reduces operational expenses.
Application Areas
The ABB CB801 3BSE042245R1 excels in industries requiring reliable and high-speed communication:
- Manufacturing: Powers assembly lines, robotic arms, and conveyor systems, ensuring synchronized operation and rapid error correction.
- Energy: Supports power plant turbines, substations, and renewable energy installations, enabling real-time monitoring of critical assets.
- Chemical & Petrochemical: Manages distributed control systems (DCS) in hazardous environments, ensuring compliance with safety standards.
- Water Treatment: Controls pumps, valves, and filtration systems in wastewater plants, optimizing resource allocation and reducing downtime.
- Building Automation: Integrates HVAC systems, elevators, and security networks in smart buildings, enhancing energy efficiency and occupant comfort.
CB801 3BSE042245R1
Related Products
- ABB CI854AK03 3BSE030220R1: PROFIBUS DP master module for centralized control in AC800M systems.
- ABB CB802 3BSE042246R1: Enhanced version of the CB801 3BSE042245R1 with additional diagnostic features.
- ABB PP886R 3BSE024547R1: Panel 800 HMI with built-in PROFIBUS DP connectivity.
- ABB AC500 PLC 3BSE032695R1: Compact PLC compatible with the CB801 3BSE042245R1 for modular automation.
- ABB S800 I/O 3BSE043660R1: Distributed I/O system for scalable industrial control.
- ABB DSAI133A 3BSE018290R1: High-precision analog input module for sensor integration.
- ABB DSAP130 3BSE018288R1: Digital output module for actuator control.
Installation and Maintenance
Installation Preparation:
Mount the CB801 3BSE042245R1 in a DIN rail enclosure, ensuring proper grounding and cable routing. Use shielded PROFIBUS DP cables to minimize interference, and maintain a 15 cm separation from power cables to comply with electromagnetic compatibility (EMC) standards . Configure the module’s node address and baud rate using ABB’s Automation Builder software or via the SD card.
Mount the CB801 3BSE042245R1 in a DIN rail enclosure, ensuring proper grounding and cable routing. Use shielded PROFIBUS DP cables to minimize interference, and maintain a 15 cm separation from power cables to comply with electromagnetic compatibility (EMC) standards . Configure the module’s node address and baud rate using ABB’s Automation Builder software or via the SD card.
Maintenance Recommendations:
- Regular Inspections: Check for loose connections, corrosion, or physical damage during routine maintenance.
- Firmware Updates: Keep the module’s firmware updated via ABB’s official channels to access new features and security patches.
- Environmental Monitoring: Ensure the operating temperature and humidity remain within specified ranges to prevent premature component failure.
- Spare Parts Inventory: Maintain a backup CB801 3BSE042245R1 module to reduce downtime in case of hardware failure.
CB801 3BSE042245R1
Product Guarantee
Chengdu Sunshine XiHe Electric Co., LTD, a leading industrial automation distributor since 2007, offers a 1-year warranty on the ABB CB801 3BSE042245R1. This warranty covers defects in materials and workmanship, with repairs handled by certified technicians. As a trusted supplier of rare and obsolete industrial control spare parts, we ensure rapid delivery and 24/7 technical support to minimize downtime. Our extensive inventory and global sourcing network enable us to meet urgent requirements efficiently, supporting industries worldwide with reliable automation solutions.
