Product Overview
The Hirschmann MM20 – Z6Z6Z6Z6SAHH is a high – performance media module designed by Hirschmann, a renowned name in the industrial networking domain. As part of the MM20 series, it is specifically engineered for use in the MS 20/30 series of modular Ethernet switches, bringing enhanced connectivity options to industrial automation setups.
This module serves as a crucial component for establishing reliable and high – speed communication links within industrial networks. With its 4 open 100MB fiber Small Form – Factor Pluggable (SFP) slots, the Hirschmann MM20 – Z6Z6Z6Z6SAHH offers great flexibility in connecting various fiber – optic – enabled devices. SFP modules, which are sold separately, can be inserted into these slots, allowing for customization based on specific application requirements.E-mail :sales@ygplc.com. Whether it’s connecting to sensors, actuators, or other network – enabled devices in a factory automation setting, or establishing long – distance communication links between different parts of an industrial plant, this module ensures seamless data transfer.
In the context of industrial automation systems, the Hirschmann MM20 – Z6Z6Z6Z6SAHH plays a pivotal role in maintaining network integrity. Its compatibility with the MS 20/30 series switches, which are known for their robustness and reliability in industrial environments, makes it an ideal choice for applications where continuous operation and high – quality data transmission are essential. By enabling the use of fiber – optic technology, it provides immunity to electromagnetic interference, a common issue in industrial settings filled with large amounts of electrical equipment, ensuring stable and accurate data communication.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | MM20 – Z6Z6Z6Z6SAHH |
| Manufacturer | Hirschmann |
| Product Type | Media Module |
| Number of Ports | 4 (100MB fiber SFP slots) |
| Series | MM20 |
| Switch Compatibility | MS 20/30 series modular Ethernet switches |
| Temperature Range | Standard: 0 °C to + 60 °C (Options for – 40 °C to + 70 °C available) |
| Hazardous Location Rating | Class 1 Div. II rated |
| Dimensions | [Specify if available, e.g., length x width x height] |
| Mounting Method | Designed for installation in MS 20/30 series switch chassis |
| Power Requirements | Power is typically provided through the host switch; consult switch documentation for details |
| Data Transfer Rate | Up to 100Mbps per SFP port (dependent on SFP module used) |
MM20-Z6Z6Z6Z6SAHH
Main Features and Advantages
Flexibility in Connectivity
The Hirschmann MM20 – Z6Z6Z6Z6SAHH stands out for its flexibility in connectivity options. With 4 open SFP slots, it can accommodate a wide variety of SFP modules. This means that users can choose the SFP modules based on factors such as the type of fiber (single – mode or multi – mode), distance requirements, and the specific needs of the connected devices. For example, in a large – scale industrial complex where some connections need to span long distances, single – mode SFP modules can be used, while for shorter – range, high – density connections, multi – mode SFP modules are a suitable choice. This adaptability allows for the optimization of the network infrastructure according to the unique demands of each industrial application.Whatsapp:+86 18859254943.
High – Quality Data Transmission
By leveraging fiber – optic technology through its SFP slots, the module ensures high – quality data transmission. Fiber – optic cables are highly resistant to electromagnetic interference, which is prevalent in industrial environments. In areas filled with motors, generators, and other electrical equipment that can generate significant electromagnetic noise, the MM20 – Z6Z6Z6Z6SAHH can maintain a stable and reliable data connection. This results in accurate and fast data transfer, reducing the likelihood of data errors and improving the overall performance of the industrial automation system. For applications such as real – time monitoring and control, where timely and accurate data is crucial, this feature is of utmost importance.E-mail :sales@ygplc.com.
Compatibility and Ease of Integration
Designed specifically for the MS 20/30 series of modular Ethernet switches, the Hirschmann MM20 – Z6Z6Z6Z6SAHH offers seamless compatibility and ease of integration. The modular design of the MS 20/30 series allows for quick and straightforward installation of the MM20 – Z6Z6Z6Z6SAHH module. It simply slots into the switch chassis, and with the help of user – friendly configuration tools provided by Hirschmann, engineers can set up the module and configure its communication parameters with minimal effort. This not only reduces the installation time but also minimizes the potential for errors during the integration process, making it an attractive option for both new industrial projects and the expansion or upgrade of existing systems.
MM20-Z6Z6Z6Z6SAHH
Robust Design for Industrial Environments
Hirschmann is known for its robust product designs, and the MM20 – Z6Z6Z6Z6SAHH is no exception. It is built to withstand the harsh conditions often found in industrial settings. With a standard operating temperature range of 0 °C to + 60 °C, and options for an even wider range of – 40 °C to + 70 °C, it can operate reliably in environments with extreme temperatures. Additionally, its Class 1 Div. II rating indicates that it is suitable for use in hazardous locations where there may be a risk of explosion due to the presence of flammable gases, vapors, or dust. This robust construction ensures the module can maintain its performance over time, reducing the need for frequent replacements and maintenance, and ultimately saving costs for industrial operators.Whatsapp:+86 18859254943.
Application Areas
Industrial Automation in Manufacturing Plants
In manufacturing plants, the Hirschmann MM20 – Z6Z6Z6Z6SAHH is extensively used to connect different components of the automated production line. It can link robotic arms, conveyor belts, Programmable Logic Controllers (PLCs), and sensors together. For instance, in an automotive manufacturing plant, it can enable high – speed data transfer between the PLCs controlling the assembly process and the sensors monitoring the quality of each component. The fiber – optic connectivity provided by the module ensures that data is transmitted accurately and quickly, even in the presence of electrical noise generated by the numerous motors and machinery in the plant. This helps in optimizing the production process, reducing errors, and increasing overall productivity.
Process Control in Chemical and Petrochemical Industries
In chemical and petrochemical industries, process control is of critical importance. The MM20 – Z6Z6Z6Z6SAHH is used to establish reliable communication links between various process control systems, such as Distributed Control Systems (DCS) and Supervisory Control and Data Acquisition (SCADA) systems, and the field devices like valves, pumps, and flow meters. The fiber – optic SFP connections offer the necessary bandwidth and immunity to electromagnetic interference, which is essential for accurate and real – time monitoring and control of chemical reactions and fluid flow. In a petrochemical refinery, for example, the module can ensure that data from sensors located in hazardous areas, such as near storage tanks or pipelines, is transmitted safely and securely to the control room for analysis and decision – making.
MM20-Z6Z6Z6Z6SAHH
Power Generation and Distribution
In power generation plants, whether they are thermal, nuclear, or renewable energy facilities, the Hirschmann MM20 – Z6Z6Z6Z6SAHH plays a vital role in maintaining communication between different parts of the power generation and distribution network. It can connect the control systems of turbines, generators, and transformers to the monitoring and control stations. In a wind farm, for instance, the module can be used to transmit data from individual wind turbines to the central control center over long distances using fiber – optic cables. The high – speed and reliable data transfer capabilities of the module ensure that the power generation process can be optimized based on real – time data, such as wind speed and turbine performance, and any issues can be detected and addressed promptly to maintain the stability of the power supply.
Transportation and Logistics
In the transportation and logistics sector, the MM20 – Z6Z6Z6Z6SAHH is used to support communication in various applications. In a port, for example, it can be used to connect the cranes, automated guided vehicles (AGVs), and the terminal management system. The fiber – optic connectivity allows for fast and reliable data transfer, which is crucial for coordinating the movement of goods, ensuring efficient loading and unloading operations. In railway systems, the module can be used to establish communication between train control systems, trackside sensors, and the central control station, enabling real – time monitoring of train positions, speeds, and the condition of the tracks, enhancing the safety and efficiency of rail transportation.
Related Products
- Hirschmann MM20 – M4M4T1T1SAHH: This module is also part of the MM20 series. It has a different port configuration compared to the MM20 – Z6Z6Z6Z6SAHH, with 4 M12 D – coded Ethernet ports (10/100 Mbps), 4 M12 X – coded Ethernet ports (1000 Mbps), and 2 gigabit copper ports (RJ45 interface). While the MM20 – Z6Z6Z6Z6SAHH focuses on fiber – optic SFP – based connectivity, the MM20 – M4M4T1T1SAHH offers a mix of copper and different types of Ethernet ports, providing an alternative for applications where a combination of these interfaces is required.
- Hirschmann MS20 – 1600SAAEHC: This is a modular Ethernet switch from Hirschmann with which the MM20 – Z6Z6Z6Z6SAHH is compatible. The MS20 – 1600SAAEHC provides the chassis and power supply for the MM20 – Z6Z6Z6Z6SAHH module. It has multiple slots where different media modules, including the MM20 – Z6Z6Z6Z6SAHH, can be installed, allowing for the customization of the switch’s port configuration based on the network requirements.
- Hirschmann SFP Modules: These are the Small Form – Factor Pluggable modules that can be inserted into the 4 SFP slots of the MM20 – Z6Z6Z6Z6SAHH. Different types of SFP modules are available, such as single – mode and multi – mode fiber modules, with varying data transfer rates and transmission distances. For example, a single – mode SFP module with a longer transmission distance can be used in applications where devices are located far apart, while a multi – mode SFP module with a higher data transfer rate can be chosen for high – density, short – range connections.E-mail :sales@ygplc.com.
- Hirschmann MM2 – 2FXM2: Another media module in the Hirschmann product line. It has 2 fiber – optic ports and is designed for more basic fiber – optic connectivity needs. Compared to the MM20 – Z6Z6Z6Z6SAHH which has 4 SFP slots for more flexible and potentially complex fiber – optic setups, the MM2 – 2FXM2 is a simpler option for applications that only require a couple of fiber – optic connections.
- Hirschmann MM3 – 4TX1 – RT EEC: This module offers 4 Ethernet ports and is designed for real – time applications. While the MM20 – Z6Z6Z6Z6SAHH focuses on fiber – optic – based high – speed data transfer, the MM3 – 4TX1 – RT EEC may be used in scenarios where real – time data transmission over Ethernet cables is a priority, and it can be integrated with the MM20 – Z6Z6Z6Z6SAHH in more complex industrial network architectures to meet different communication requirements.
MM20-Z6Z6Z6Z6SAHH
Installation and Maintenance
Installation Preparations: Before installing the Hirschmann MM20 – Z6Z6Z6Z6SAHH, ensure that the power to the MS 20/30 series switch chassis is turned off to avoid electrical hazards. Check the compatibility of the module with the specific model of the switch chassis. Prepare the appropriate SFP modules according to the requirements of the application, making sure they are properly inserted into the 4 SFP slots of the MM20 – Z6Z6Z6Z6SAHH. When inserting the module into the switch chassis, carefully align it with the slots and firmly push it in until it is securely seated. After installation, power on the switch and use the provided configuration tools, such as the web – based interface or command – line interface, to set up the module’s communication parameters, including IP address, subnet mask, and VLAN settings.Whatsapp:+86 18859254943.
Maintenance Recommendations: Regularly monitor the status of the Hirschmann MM20 – Z6Z6Z6Z6SAHH through the switch’s management interface. Check for any error indicators or abnormal behavior, such as high packet loss or slow data transfer rates. Periodically clean the SFP ports and the module’s exterior to remove dust and debris, as these can affect the performance of the fiber – optic connections. If an SFP module fails or needs to be replaced, power off the switch, carefully remove the faulty module, and insert a new, compatible SFP module. Keep the module’s firmware up – to – date by checking for and installing any available updates from Hirschmann, as these can improve performance, add new features, and address security vulnerabilities.
Maintenance Recommendations: Regularly monitor the status of the Hirschmann MM20 – Z6Z6Z6Z6SAHH through the switch’s management interface. Check for any error indicators or abnormal behavior, such as high packet loss or slow data transfer rates. Periodically clean the SFP ports and the module’s exterior to remove dust and debris, as these can affect the performance of the fiber – optic connections. If an SFP module fails or needs to be replaced, power off the switch, carefully remove the faulty module, and insert a new, compatible SFP module. Keep the module’s firmware up – to – date by checking for and installing any available updates from Hirschmann, as these can improve performance, add new features, and address security vulnerabilities.
Product Assurance
Our company provides a one – year quality warranty for the Hirschmann MM20 – Z6Z6Z6Z6SAHH, covering hardware failures due to non – human factors. During the warranty period, if the product exhibits performance anomalies or functional failures, we will provide replacement services. Moreover, for discontinued models or urgent requirements, we rely on our global supply chain network to quickly respond to customers’ procurement needs for scarce spare parts. With 17 years of experience in the industrial control industry, we are committed to ensuring that your industrial systems can operate continuously and stably, backed by our reliable product assurance services.E-mail :sales@ygplc.com.
