KEYSYS-RJ-16CH-AD
KEYSYS-RJ-16CH-AD
KEYSYS-RJ-16CH-AD
KEYSYS-RJ-16CH-AD
KEYSYS-RJ-16CH-AD
KEYSYS-RJ-16CH-AD

KEYSYS-RJ-16CH-AD | KEYSYS-RT-16CH-AD

Original price was: $500.00.Current price is: $398.00.

The KEYSYS KEYSYS-RJ-16CH-AD is a high-performance industrial automation module designed for precise analog-to-digital conversion and multi-channel data acquisition. As a critical component in industrial control systems, this module combines 16 isolated analog input channels with advanced signal conditioning capabilities, making it ideal for applications requiring reliable conversion of analog signals into digital data for processing by PLCs, DCS systems, or industrial computers.
Product Model：KEYSYS-RJ-16CH-AD
Manufacturer：KEYSYS
Product Type：Industrial Analog-to-Digital Conversion Module
Input Channels：16 isolated channels
Input Signal Types：Voltage (±10V, ±5V), Current (4-20mA)
Resolution：16 bits
Sampling Rate：100 kS/s

Get a Quote
Category: Brand:

Description

Product Overview
The KEYSYS KEYSYS-RJ-16CH-AD is a high-performance industrial automation module designed for precise analog-to-digital conversion and multi-channel data acquisition. As a critical component in industrial control systems, this module combines 16 isolated analog input channels with advanced signal conditioning capabilities, making it ideal for applications requiring reliable conversion of analog signals into digital data for processing by PLCs, DCS systems, or industrial computers.



Built on KEYSYS’ robust industrial platform, the KEYSYS-RJ-16CH-AD supports a wide range of analog input types, including voltage (±10V, ±5V) and current (4-20mA) signals, ensuring compatibility with sensors and transducers across diverse industries. Its modular design features RJ45 connectors for secure and standardized wiring, simplifying integration into existing control architectures. With a conversion resolution of 16 bits and a sampling rate of 100 kS/s, the module delivers high accuracy and real-time data processing, making it suitable for demanding environments such as process control, machinery monitoring, and energy management systems.Whatsapp:+86 18859254943.

In industrial automation, the KEYSYS-RJ-16CH-AD serves as a bridge between analog field devices and digital control systems. By converting raw analog signals into digital values, it enables precise monitoring of parameters like temperature, pressure, and flow rate, ensuring optimal system performance and predictive maintenance. Its compact form factor and DIN-rail mountable design facilitate easy installation in control panels, while built-in surge protection and EMI/RFI immunity ensure reliable operation in harsh industrial settings.

KEYSYS-RJ-16CH-AD

KEYSYS-RJ-16CH-AD

Technical Specifications

Parameter Name Parameter Value
Product Model KEYSYS-RJ-16CH-AD
Manufacturer KEYSYS
Product Type Industrial Analog-to-Digital Conversion Module
Input Channels 16 isolated channels
Input Signal Types Voltage (±10V, ±5V), Current (4-20mA)
Resolution 16 bits
Sampling Rate 100 kS/s
Input Impedance ≥10 MΩ (voltage), 250 Ω (current)
Communication Interface RS485 (Modbus RTU)
Power Supply 24 V DC ±10%
Power Consumption ≤5 W
Operating Temperature -20°C to +60°C
Storage Temperature -40°C to +85°C
Protection Level IP20 (front panel), surge protection
Dimensions (W×H×D) 125 mm × 100 mm × 75 mm
Mounting Method DIN-rail (35 mm)

Main Features and Advantages

High-Precision Signal Conversion

The KEYSYS-RJ-16CH-AD offers 16-bit resolution and a wide input range, ensuring accurate measurement of both small and large analog signals. Its high sampling rate allows for real-time data acquisition, critical for applications requiring rapid response to changing process conditions.Whatsapp:+86 18859254943.

Isolated Channels for Enhanced Safety

Each of the 16 input channels is galvanically isolated, protecting the module and connected devices from ground loops and voltage spikes. This isolation is particularly vital in environments with high electromagnetic interference (EMI) or where sensor wiring spans long distances.

KEYSYS-RJ-16CH-AD

KEYSYS-RJ-16CH-AD

Flexible Configuration and Compatibility

The module supports multiple analog signal types and can be configured via software to match specific application requirements. Its RS485 interface with Modbus RTU protocol ensures seamless integration with 主流 industrial control systems, while RJ45 connectors simplify wiring and reduce installation time.

Rugged Industrial Design

Designed for harsh environments, the KEYSYS-RJ-16CH-AD operates reliably across a wide temperature range and features built-in surge protection. Its compact DIN-rail mountable design optimizes space in control panels, making it suitable for retrofitting or new installations.

Easy Maintenance and Diagnostics

The module includes diagnostic features such as channel status indicators and error reporting, enabling quick troubleshooting. Its modular construction allows for individual channel replacement without disrupting the entire system, minimizing downtime.E-mail :sales@ygplc.com.

Application Areas

Process Control Systems

In chemical and petrochemical plants, the KEYSYS-RJ-16CH-AD converts analog signals from pressure transmitters, flow meters, and temperature sensors into digital data for DCS or PLC systems. This ensures precise regulation of processes like reactor temperature control and chemical dosing.

KEYSYS-RJ-16CH-AD

KEYSYS-RJ-16CH-AD

Machinery Monitoring

In manufacturing, the module monitors vibration, load, and torque signals from motors and rotating equipment. By providing real-time data to predictive maintenance systems, it helps identify potential failures before they escalate, reducing downtime and maintenance costs.

Energy Management

In power generation and distribution, the KEYSYS-RJ-16CH-AD measures analog signals from generators, transformers, and grid infrastructure. This data is used to optimize energy output, monitor grid stability, and ensure compliance with regulatory standards.

Building Automation

In smart buildings, the module interfaces with HVAC systems, lighting controls, and environmental sensors. By converting analog signals from these devices, it enables centralized monitoring and automation, enhancing energy efficiency and occupant comfort.E-mail :sales@ygplc.com.

Transportation Infrastructure

In railways and ports, the KEYSYS-RJ-16CH-AD processes analog signals from trackside sensors, cranes, and automated guided vehicles (AGVs). This supports real-time monitoring of equipment status and ensures safe, efficient operations.

KEYSYS-RJ-16CH-AD

KEYSYS-RJ-16CH-AD

Related Products

  1. KEYSYS-RJ-8CH-AD: A 8-channel analog-to-digital conversion module with similar specifications, suitable for smaller-scale applications requiring fewer input channels.
  2. KEYSYS-RJ-16CH-DA: A complementary digital-to-analog conversion module for output control, often used alongside the KEYSYS-RJ-16CH-AD in closed-loop control systems.
  3. KEYSYS-RJ-COM: A communication gateway module that expands connectivity options, supporting protocols like Profibus or Ethernet/IP.
  4. KEYSYS-RJ-PWR: A dedicated power supply module designed to provide stable 24 V DC power for KEYSYS-RJ-16CH-AD and other compatible devices.
  5. KEYSYS-RJ-TERM: A terminal block adapter for the KEYSYS-RJ-16CH-AD, offering secure wiring connections for analog inputs and power.

Installation and Maintenance

Installation Preparations:
Before installing the KEYSYS-RJ-16CH-AD, ensure the power to the control system is disconnected. Verify the module’s compatibility with your control system’s communication protocol and configure the input signal types via software. Mount the module on a 35 mm DIN rail using the provided brackets, ensuring proper alignment and secure fastening. Connect the analog inputs using shielded cables terminated with RJ45 connectors, and link the RS485 interface to the control system’s master device. Finally, apply power and perform a diagnostic check to confirm proper operation.



Maintenance Recommendations:
Regularly inspect the KEYSYS-RJ-16CH-AD for physical damage or loose connections. Clean the module with a dry cloth to remove dust and debris, ensuring proper heat dissipation. Monitor the diagnostic indicators for any error codes, which may signal issues like sensor malfunctions or communication failures. Periodically recalibrate the module using factory-recommended procedures to maintain accuracy. For firmware updates or advanced troubleshooting, consult KEYSYS’ technical documentation or contact our support team.

KEYSYS-RJ-16CH-AD

KEYSYS-RJ-16CH-AD

Product Assurance

Our company provides a one-year quality warranty for the KEYSYS-RJ-16CH-AD, covering hardware failures due to non-human factors. During the warranty period, we will replace any defective components at no additional cost. E-mail :sales@ygplc.com.For discontinued models or urgent requirements, our global supply chain network ensures rapid delivery of scarce spare parts. With 17 years of experience in industrial control distribution, we guarantee reliable support for your automation needs, from pre-sales technical 咨询 to post-installation maintenance. Trust us to keep your systems running efficiently and securely.
