PM861AK01 | PM861K01 | PM861AK02 | High-Power Processor Unit | Industrial Automation

Description

Brand：ABB

Model：PM861AK01

Product Parameters

• Condition: Factory-new, rigorously tested to meet ABB’s stringent quality standards, ensuring optimal performance in critical industrial environments.
• Warranty: 12-month manufacturer’s warranty covering defects in materials and workmanship under normal use.
• Package: Secure anti-static packaging with foam padding, including mounting brackets, user manual, and calibration certificate.
• Mounting Type: DIN rail or panel-mountable via screw holes, compatible with standard industrial enclosures for flexible installation.
• Dimensions: Compact design (119 mm depth × 189 mm height × 135 mm width) for space-efficient integration in retrofitted or new systems.
• Surge Protection: Built-in transient voltage suppression up to 2.5 kV (IEC 61000-4-5) safeguards against electrical surges and grid instability.
• Compliance:
  • IEC 61850, IEC 60870-5-103, Modbus®, and DNP 3.0 for communication protocols.
  • IEC 61131-2 (industrial control), UL 508 (safety), and DNV certification for marine/offshore use.
• Application: Power distribution, industrial automation, renewable energy systems, marine/offshore environments, and transportation.

Product Introduction

1. Powerful Processing: Equipped with a high-speed 32-bit RISC microprocessor, the PM861AK01 efficiently handles complex calculations and real-time data processing, ensuring rapid response to dynamic system requirements.
2. Flexible I/O Interfaces: Supports multiple communication protocols (Ethernet, RS-232/485) and expansion modules, enabling connectivity with sensors, actuators, and third-party devices.
3. Wide Operating Range: Operates reliably in extreme temperatures (-25°C to +60°C) and harsh environments, making it suitable for challenging industrial settings.
4. Modular Design: Easy-to-install and scalable architecture allows for incremental system expansion without downtime.
5. Enhanced Safety: Built-in overload and short-circuit protection mechanisms ensure system stability and prevent damage during fault conditions.

• Memory Capacity: 16 MB RAM and 128 MB flash memory for efficient data storage and program execution.
• Energy Efficiency: Low power consumption (≤20 W) reduces operational costs and heat generation.
• Remote Management: Configurable via ABB’s Automation Builder software for remote diagnostics and firmware updates.

• Works with ABB’s 800xA and Symphony Plus systems, as well as third-party PLCs via Modbus RTU or Profibus DP.
• Supports redundant CPU configurations for high-availability systems, ensuring uninterrupted operation.

Product Application Industry

1. Power Distribution
   • Substations: Monitors and controls power flow in medium-voltage networks, ensuring grid stability and compliance with regulatory standards.
   • Renewable Energy: Manages energy conversion in solar/wind farms and stabilizes microgrids for efficient grid integration.
2. Industrial Automation
   • Manufacturing: Controls robotic systems, conveyor belts, and assembly lines in automotive and electronics production.
   • Machinery: Manages motor drives and precision machinery in metalworking and textile industries.
3. Marine & Offshore
   • Vessel Power Systems: Protects onboard electrical networks and offshore platforms, certified by DNV for marine use.
   • Drilling Rigs: Ensures reliable control of pumps and valves in harsh offshore environments.
4. Transportation
   • Railways: Manages signaling systems and traction power for trains and metros.
   • Aviation: Controls ground support equipment and airport infrastructure.
5. Water/Wastewater Treatment
   • Process Control: Monitors and optimizes treatment processes for water distribution and sewage systems.
   • Pump Stations: Ensures efficient operation of pumps and valves to meet environmental compliance.

• Cost Efficiency: Reduces maintenance costs through modular design and remote diagnostics.
• Scalability: Adaptable to evolving system needs with expansion modules.
• Safety Compliance: Meets global standards for hazardous environments, ensuring operator and equipment protection.
