The TRICONEX DO3401 stands out as a leading digital output solution for safety-critical applications, combining advanced redundancy, fail-safe design, and intelligent control features to deliver unmatched reliability and performance.
Product Model：DO3401
Manufacturer：TRICONEX
Product Type：Digital Output Module (Triple Modular Redundant, Fail-Safe Capable)
Output Voltage Range：24 VDC (±10%)
Number of Channels：16 channels (isolated, 8 channels per submodule)
Output Type：Solid-state (MOSFET) with fault current limiting

Get a Quote
Category: Brand:

Description

Product Overview

The TRICONEX DO3401 is a high-integrity digital output module engineered for safety-critical industrial control systems, belonging to TRICONEX’s renowned Tricon series—a platform celebrated for its triple modular redundancy (TMR) architecture. Designed to deliver deterministic control signals to field devices, the TRICONEX DO3401 serves as a cornerstone component in systems where precise actuation and fault tolerance are non-negotiable, such as safety instrumented systems (SIS), emergency shutdown (ESD) systems, and complex process control applications.



As a digital output module, the TRICONEX DO3401 translates control system commands into discrete output signals (on/off, energize/de-energize) to drive devices like valves, contactors, and motor starters. Its core functionality lies in its ability to execute output commands with precision while ensuring signal integrity through advanced diagnostic features and hardware redundancy. The module’s TMR design triplicates critical components—including microprocessors, output drivers, and communication paths—allowing it to tolerate single-point failures without compromising performance. This architecture ensures that the TRICONEX DO3401 meets the stringent safety requirements of industries where system failure could lead to severe consequences, such as oil and gas refining, chemical processing, and power generation.Whatsapp:+86 18859254943.



In the context of industrial automation, the TRICONEX DO3401 acts as a bridge between the control system and field devices, enabling safe and reliable actuation. Its robust construction and intelligent diagnostics make it suitable for harsh environments characterized by high electrical noise, temperature extremes, and mechanical stress. By integrating this module into a Tricon system, users can achieve enhanced system availability, reduced downtime, and compliance with international safety standards like IEC 61508 and IEC 61511, ensuring operational continuity and protection of personnel and assets.

DO3401

DO3401

Technical Specifications

Parameter Name Parameter Value
Product Model DO3401
Manufacturer TRICONEX
Product Type Digital Output Module (Triple Modular Redundant, Fail-Safe Capable)
Output Voltage Range 24 VDC (±10%)
Number of Channels 16 channels (isolated, 8 channels per submodule)
Output Type Solid-state (MOSFET) with fault current limiting
Output Current Capacity 2 A per channel (continuous), 3 A peak (10 seconds)
Fault Detection Real-time diagnostics for open circuit, short circuit, overcurrent, and loss of view (FVD: Force-to-Value Diagnostic)27
Communication Protocol Tricon proprietary backplane communication (10 Mbps, dual-redundant)
Operating Temperature -40°C to +70°C (-40°F to +158°F)
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Vibration Resistance 2 g peak, 5 Hz to 200 Hz (per IEC 60068-2-6)
Shock Resistance 15 g peak, 11 ms (per IEC 60068-2-27)
Physical Dimensions 175 mm (H) x 100 mm (W) x 220 mm (D) (6.89 in x 3.94 in x 8.66 in)
Installation Method Rack-mounted (compatible with Tricon 3000/4000 series chassis, hot-swappable)
Safety Integrity Level SIL 3 capable (when used in a properly configured TMR system, per IEC 61508)813

Main Features and Advantages

The TRICONEX DO3401 stands out as a leading digital output solution for safety-critical applications, combining advanced redundancy, fail-safe design, and intelligent control features to deliver unmatched reliability and performance.

Triple Modular Redundancy (TMR) Architecture

At the heart of the TRICONEX DO3401 is its TMR design, which triples all critical components to provide inherent fault tolerance. Each output channel is managed by three independent submodules, with a majority-vote mechanism ensuring that only valid commands are executed. This design allows the module to continue operating even if one submodule fails, eliminating single points of failure and ensuring continuous system availability. The TMR architecture also enables online maintenance, as failed submodules can be replaced without shutting down the system, minimizing downtime in critical operations37.E-mail :sales@ygplc.com.

DO3401

DO3401

Fail-Safe Output Configuration

The module supports configurable fail-safe states, allowing users to define the default output state (e.g., de-energized, last valid value) in the event of a communication loss or module fault. This feature is critical for safety systems, where predefined fail-safe actions can prevent hazardous conditions. Whether used to trip a valve in an emergency or maintain a safe process state, the TRICONEX DO3401 ensures that the system responds appropriately to unexpected events, aligning with industry best practices for safety instrumented systems20.Whatsapp:+86 18859254943.

Comprehensive Diagnostic Capabilities

Built-in self-diagnostics continuously monitor the module’s health, including output circuit integrity, power supply stability, and thermal conditions. Advanced features such as channel-specific fault detection (open/short circuit, overcurrent) and force-to-value diagnostics (FVD) provide real-time feedback to the control system, enabling proactive maintenance and rapid issue resolution. These diagnostics are compliant with SIL 3 requirements, allowing users to maintain the highest levels of safety integrity while reducing the risk of unplanned outages27.

Flexible and Robust Signal Handling

The TRICONEX DO3401 supports solid-state (MOSFET) outputs with fault current limiting, making it compatible with a wide range of field devices, from low-power indicators to high-current contactors. Its isolated channels prevent cross-talk and ground loops, while adjustable signal filtering enhances noise immunity in electrically challenging environments. The module’s self-limiting output current ensures safe operation even under fault conditions, protecting both the module and connected equipment223.

Rugged Industrial Design

Engineered for harsh industrial environments, the TRICONEX DO3401 features a robust enclosure and thermal management system that ensures reliable operation across extreme temperatures and vibrations. Its electromagnetic interference (EMI) shielding protects against external noise, ensuring signal purity and control accuracy. Whatsapp:+86 18859254943.This durability makes it an ideal choice for offshore platforms, refineries, and other challenging installations where equipment must perform reliably over long service lifetimes320.

Application Areas

The TRICONEX DO3401 is purpose-built for applications requiring precise, safe, and reliable digital actuation, making it indispensable in industries where control system accuracy directly impacts safety and productivity:

Oil and Gas Processing

In upstream and downstream oil and gas facilities, the module controls critical field devices such as emergency shutdown valves, pump starters, and flare systems. Its fail-safe capabilities and TMR architecture ensure that in the event of a fault, the system can safely transition to a predefined state, preventing leaks, overpressure, or other hazardous conditions813.

Chemical and Petrochemical Plants

Within chemical processing units, the TRICONEX DO3401 drives valves, agitators, and safety interlocks in reaction vessels and distillation columns. Its ability to handle high-current loads and provide real-time diagnostics is essential for maintaining process stability and complying with strict safety regulations, such as those governing flammable substance handling320.

Power Generation

In thermal, nuclear, and renewable power plants, the module controls circuit breakers, generator exciters, and turbine bypass valves. Its hot-swappable design and redundant communication links are critical for maintaining grid stability, as they allow maintenance without interrupting power production—a non-negotiable requirement in utility-scale operations713.

DO3401

DO3401

Industrial Safety Systems

As a key component of safety instrumented systems (SIS), the TRICONEX DO3401 executes safety logic commands, such as initiating shutdown sequences or activating fire suppression systems. Its SIL 3 capability ensures that it can be used in the most critical safety loops, where every actuation must be both precise and dependable812.



Heavy Machinery and Manufacturing

In manufacturing facilities and heavy machinery applications, the module controls conveyor belts, robotic arms, and safety guards, ensuring synchronized operation and worker protection. Its rugged design withstands the mechanical vibrations and electrical noise common in these environments, delivering consistent performance over extended periods323.

Related Products

The TRICONEX DO3401 is part of TRICONEX’s comprehensive Tricon ecosystem, designed to work seamlessly with other modules and systems for end-to-end control solutions. Below are key related products and their roles:



  • TRICONEX DI3361: A complementary digital input module that captures discrete signals from field devices, working alongside the DO3401 to form a complete input/output (I/O) solution for safety systems714.Whatsapp:+86 18859254943.
  • TRICONEX AI3100: An analog input module that provides continuous process variable monitoring, enabling the DO3401 to act on data from sensors like temperature and pressure transmitters714.
  • TRICONEX Tricon Controller 4000: The central processing unit that executes control logic and safety algorithms, integrating data from the DO3401 and other modules to drive system-wide decisions713.
  • TRICONEX DO3203: A high-density digital output module with 32 channels, ideal for applications requiring more output points while maintaining TMR redundancy714.
  • TRICONEX FTA3300: A field termination assembly that provides a secure interface between the DO3401 and field wiring, simplifying installation and maintenance714.
  • TRICONEX Power Supply PS3040: A redundant power supply module that ensures stable power delivery to the DO3401 and other Tricon components, even during transient power fluctuations714.
  • TRICONEX Communication Module CM3008: Enables the DO3401 to communicate with external systems via protocols like Modbus, Ethernet/IP, or Profibus, enhancing interoperability with higher-level control systems714.
  • TRICONEX IO Expansion Chassis: Allows users to scale their Tricon system by adding more modules, including the DO3401, to meet increasing I/O requirements in complex installations714.
    DO3401

    DO3401

Installation and Maintenance

Installation Preparation

Before installing the TRICONEX DO3401, ensure the Tricon chassis is powered off and properly grounded to prevent electrostatic discharge (ESD) damage. Verify compatibility with the chassis model (e.g., Tricon 3000/4000 series) and confirm that the controller firmware is up-to-date. Prepare field wiring by terminating output signals to the associated field termination assembly (FTA), ensuring correct polarity and load current ratings for each channel.E-mail :sales@ygplc.com. Label all connections clearly to facilitate future troubleshooting. When inserting the module into the chassis, align it with the guide rails and secure it with the retaining clips to ensure a stable mechanical and electrical connection720.

Maintenance Recommendations

Regular maintenance is essential to maximize the lifespan and reliability of the TRICONEX DO3401. Use the control system’s diagnostic interface to monitor module health, including channel status, temperature, and communication link integrity. If a fault is detected (e.g., a channel reports a short circuit), leverage the module’s hot-swappable design to replace the affected submodule without powering down the system, minimizing downtime. Inspect field connections periodically for signs of wear or loose terminals, tightening connections as needed to prevent voltage drops or intermittent faults. Clean the module’s exterior with a dry, anti-static cloth to remove dust and debris that could impact thermal dissipation. Additionally, ensure the operating environment remains within the specified temperature and humidity ranges to avoid component degradation. Schedule annual system reviews to validate output configurations and safety logic, ensuring alignment with current process requirements and safety standards720.

DO3401

DO3401

Product Assurance

We stand behind the TRICONEX DO3401 with a comprehensive product assurance program designed to meet the rigorous demands of industrial control applications. As a trusted distributor with 17 years of experience in the industrial control sector, we offer a standard warranty that covers manufacturing defects, ensuring your investment is protected. Our dedicated technical support team is available to assist with installation, configuration, and troubleshooting, providing expert guidance to keep your systems running smoothly.



Leveraging our global supply chain and extensive inventory, we ensure fast availability of the TRICONEX DO3401, even for legacy or hard-to-find components. Whether you need a single module for a replacement or multiple units for a new project, our streamlined procurement process and stock readiness help you avoid costly delays. We are committed to delivering not just products, but reliable solutions—backed by our expertise in industrial automation and a relentless focus on customer satisfaction. Trust in our proven track record and let the TRICONEX DO3401 be the cornerstone of your safe, efficient, and high-performing control system.
